Tridon Spring Load T-Bolt 19mm - 3/4" w/Channel Bridge


Tridon Spring Load T-Bolt 19mm - 3/4" w/Channel Bridge
Purchase Tridon Spring Load T-Bolt 19mm - 3/4" w/Channel Bridge
  • Tridon Spring Load T-Bolt 19mm - 3/4" w/Channel Bridge

  • Tridon Spring Loaded T-Bolt 3/4" - 19mm clamps provide uniform sealing pressure for a positive, reliable seal. The spiral spring design compensates and provides constant tension to prevent leak paths due to temperature fluctuations. Designed for use in high vibration and large diameter applications common in heavy trucks (charge air and cooling systems), industrial machinery, off-road equipment, agricultural irrigation and machinery. Features a spring-loaded t-bolt assembly, a 3/4″-19mm wide stainless steel band and welded construction for reliability.

  • Band Material: 300SS, Hardware plated Carbon Steel
  • Band Thickness Max: 0.69
  • Band Width Max (mm): 19.3
  • Nut Hex Size S (mm) Material:
  • Max Recommended Installation Torque (Nm): 8.5




Article Number Clamping Range
819263 57-65
819275 69-77
819288 73-80
819300 76-84
819306 78-85
819325 82-90
819338 85-93
819356 90-98
819406 103-111
819413 104-112
819425 107-115
819475 120-128
819525 113-141
